PDI-HV2006MG
|
Category: |
Mini Servos |
|
{{variant.name}}:
|
{{opt.name}}
{{opt.name}}
|
Dead band: 2μs
Motor: coreless motor
Working frequence: 1520μs / 330hz
Operating Voltage: DC6.0~8.4 V
Operating Temperature Range: -10 to + 60°c
Operating Speed (6.0V): 0.07sec/60 °
Operating Speed (7.4V): 0.05sec/60°
Stall Torque (6.0V): 4.8kg.cm (67.09oz/in)
Stall Torque (7.4V): 6.2kg.cm (86.81oz/in)
Potentiometer Drive: Direct Drive
Dimensions: 23X12X27.6 mm
Weight: 20.3 g (0.72oz)
Connector Wire : Futaba/JR 200 mm
Bearing: 2BB
